ELSR-N-Halogen free

Self-regulating heating cable

Usage

  • Available in different designs for many uses
  • Frost protection and heating products
  • Power on: 65 °C
    65 °C
  • Power off: 80 °C
    80 °C
  • EX
    EX
  • Halogen free
  • Can be cut and crossed for perfect adaptation
  • UV-resistant
The self-regulating halogen-free heating cable ELSR-N-AHF/BHF free is suitable for frost protection and temperature maintenance for commercial use in the low temperature range.

ELSR-N-Halogen free

Article list

Article number Description Dimensions W x H (mm) Exposure temperature (power on), max. (ºC) Output (W/m at 10° C)
8936090 ELSR-N-10-2-AO HF 13,6 × 5,5 65 10
B0230110 ELSR-N-10-2-BO HF 14,1 × 5,8 65 10
8936092 ELSR-N-20-2-AO HF 13,6 × 5,5 65 20
B0230210 ELSR-N-20-2-BO HF 14,1 × 5,8 65 20
B0230330 ELSR-N-30-2-AO HF 13,6 × 5,5 65 30
B0230310 ELSR-N-30-2-BO HF 14,1 × 5,8 65 30
B0230430 ELSR-N-40-2-AO HF 13,6 × 5,5 65 20
B0230410 ELSR-N-40-2-BO HF 14,1 × 5,8 65 20

Specifications

Specification Data
Connection voltage 230 V
Number of conductors 2 pcs
Bending radius, min. 25 mm
Exposure temperature (power off), max. 80 ºC
Exposure temperature (power on), max. Up to 65 ºC
Contains SVHC substances according to REACH No
Installation temperature, min. -60 ºC
Insulation material inner PP
Insulation material outer PP
Cable type Self-regulating 2-conductor with screen
Conductor area 1,23 mm²
