ELSR-SHH
Self-regulating heating cable
Usage
- Wide range of uses
- Power range 15-75 W/m
- Frost protection and heating products
-
250 °C -
250 °C -
EX
-
Extremely high temperature resistance
-
High chemical resistance
-
Can be cut and crossed for perfect adaptation
The versatile self-regulating heating cable, ELSR-SHH, for high temperatures up to 250°C, can be used in a large number of industrial applications. It is also suitable and approved for use in hazardous areas. The heating cable is also resistant to reactive chemicals, oil and fuel. Thanks to the high chemical resistance, the cable also has a long service life.
Specifications
| Specification | Data |
|---|---|
| Connection voltage | 230 V |
| Number of conductors | 2 pcs |
| Bending radius, min. | 35 mm |
| Exposure temperature (power off), max. | 250 ºC |
| Exposure temperature (power on), max. | Up to 250 ºC |
| -BOT | Protective conductor: Braided, Outer casing: Fluoropolymer |
| Contains SVHC substances according to REACH | No |
| Installation temperature, min. | -40 ºC |
| Insulation material outer | PFA |
| Cable type | Self-regulating 2-conductor with screen |
| Classification (Ex) | II 2G Ex eb IIC GbII 2D Ex tb IIIC Db |
| Conductor area | 1,27 mm² |
Warranty
The general terms of delivery are listed below.
