Ebisol
Base/Insulation board
Användning
- For underfloor heating under wooden and laminate flooring
- For dry areas
- Suitable for both timber/gypsum board and concrete substrates
-
(λ) 0.034 W/mK -
(R) 0.086-0.17 m²K/W -
3.6 mm
-
Energy-efficient installation
-
Step sound attenuation
-
Replaces traditional floor foam
Ebisol is an energy-efficient base board intended for use under wood and laminate floors. The board has very good impact sound attenuation properties as well as high insulation ability. Ebisol is flexible and can be laid on most surfaces. It is easy to cut and adapt to the surface.
Specifications
| Specification | Data |
|---|---|
| Självantändningstemperatur | > +380 ºC |
| Innehåller SVHC ämnen enligt REACH | No |
| Kontinuerlig temperatur, max. | 70 ºC |
| Tryckhållfasthet (EN 16354) | 90 kPa |
| Stegljudsdämpning (EN 16354) | ≤ 22 dB |
| Löslighet | High resistance to acids and bases. Soluble in organic solvent |
| Material | HFPS foam |
| Smältpunkt | 100 ºC |
| Värmeledningsförmåga, λ | 0.034 W/mK |
Documents
Warranty
12 year product guarantee in case of material defects. The thermostat in the kit has a 5-year product guarantee. The guarantee period for the underfloor heating is extended to 25 years if the installation is carried out by an authorised electrician and documented in Ebeco's Garantera service.
