MI-H321 S/S
Series-resistive 1-conductor with screen
Användning
- Frost protection and heating products
- Also for heating
- Wide range of uses
-
650 °C -
650 °C -
EX
-
Extremely high temperature resistance
-
Ordered customized for specific needs
-
High power per meter
Mineral insulated heating cable is the ideal choice when the temperature and power requirements of an application exceed the capacity of self-regulating heating cables. They provide a reliable solution for frost protection, temperature maintenance, and process heating. The insulation of the inner heating conductors consists of magnesium oxide, a non-aging and non-combustible material. Hot and cold end connections are pre-assembled from the factory.
Specifications
| Specification | Data |
|---|---|
| Anslutningsspänning | Max 750 V |
| Anslutningskabel | Kontakta support för alternativ |
| Antal ledare | 1 st |
| Effekt | Max 250 W/m. Power and exposure temperature vary depending on the application. Contact support for alternatives |
| Exponeringstemperatur (power off), max. | 800 ºC |
| Exponeringstemperatur (power on), max. | Upp till 800 ºC |
| Installationstemperatur, min. | -60 ºC |
| Kabeltyp | Series-resistive 1-conductor with screen |
| Kapslingsklass | IP54 |
| Skyddsledare | S/S |
