Ground sensor
Active sensor
Användning
- For snow melting, ground
-
Temp & humidity -
30 mm
-
Energy savings of up to 90%
-
Adjustable according to ground level
-
Maintenance free
Combined temperature and moisture sensor for snow melting ground with adjustable sensor adapter. Used as an accessory for the EB-Therm 800 in the Max/Min mode. The adapter can be adjusted according to the completed ground level by up to 35 mm. The sensor is capacitive and thus maintenance-free. Compared to an installation with only temperature control, this combined control provides an energy saving of up to 90 %.
Transformer 24 VDC is ordered separately.
Transformer 24 VDC is ordered separately.
Ground sensor
Specifications
| Specification | Data |
|---|---|
| Anslutningsspänning | 24 VDC |
| Anslutningskabel | 6 x 0,25 mm² |
| Längd anslutningskabel | 15,0 m |
| Färg | Black |
| Brytförmåga | 200 mA |
| Diameter | 105 mm |
| Givarelement | NTC 10KΩ@25 °C |
| Fuktgivare | Capacitive - output signal 24 VDC |
| Förlängning givarkabel, max. | 50 m, 1,5 mm² |
| Innehåller SVHC ämnen enligt REACH | No |
| Kapslingsklass | IP67 |
| Kortslutningsskydd | Built-in |
| Material givarhuvud | PET, GF30% |
| Material kabel | TPE |
| Mått | Base: Ø 120 mm, housing: Ø 80 mm, total height: adjustable 75-110 mm |
| Temperaturområde | -25 °C - 70 °C |
Documents
Warranty
Ebeco AB provides a 5-year product guarantee in the event of material defects.
